How much is the 15 ton industrial steam boiler?

The 15 ton industrial steam boilers produced by ZOZEN Boiler include gas-fired industrial steam boilers, coal-fired industrial steam boilers, biomass industrial steam boilers, etc. The main types are WNS oil-fired and gas-fired industrial steam boilers, SZS oil-fired and gas-fired industrial steam boilers, and SZL coal-fired chain grate industrial steam boilers.

1, 15 tons of WNS oil-fired and gas-fired industrial steam boilers:

Boiler Model: WNS15-1.25-Y (Q)

Rated evaporation (t/h):15

Rated working pressure (Mpa): 1.25

Rated Steam Temperature (C): 194

Maximum Transportation Weight (t): 34.7

Maximum Transportation Size (m) (L*W*H): 7.0*3.1*3.6

2, 15 tons SZS oil-fired and gas-fired industrial steam boilers:

Model: SZS15-1.25/350-Q;

Rated steam temperature: 350 C.

Feed water temperature: 104 C.

Boiler design thermal efficiency: > 95%.

Smoke exhaust temperature: <80 C.

Transportation size: 9000 * 3280 * 3307.

3,15 tons SZL coal-fired chain grate industrial steam boiler:

Model Specification: SZL15-1.25-A II

Rated evaporation (t/h):15

Rated Steam Pressure (MPa): 1.25

Rated Steam Temperature (C): 226

Feedwater temperature (C):20

Exit mode: Fast loading
